WEINGARTEN HU 2-500 Double Column Press - mechanical
usadoVendedor verificado
Solicitar precio
Directamente al vendedor
1 / 1
Datos técnicos
· ID 170392557Maquinaria usada
- Estado
- usado
- Año de fabricación
- 1985
- Ubicación
- Lager Mannheim
Identifikation
FabricanteWEINGARTEN
ModeloHU 2-500
Número de artículo1050-173001V
Technik
Cantidad1
Descripción
pressure:500 t
stroke:fix 300 mm
no. of strokes:20 - 70 Hub/min
distance between columns:3100 mm
side window:1400 mm
distance table/ram, max. stroke up, adjustment up:1000 mm
Table area:2800 x 1600 mm
ram surface:2800 x 1450 mm
ram adjustment:100 mm
power requirement:90,0 kW
weight:100,0 t
Dimensions (WxDxH):5,75 x 3,2 x 7,8 m
height above floor:6,4 m
height beneath floor:1,4 m
clutch:pneumatic; Ortlinghaus
ram adjustment:motoric
overload protection in ram:hydraulic
ram counterbalance:pneumatic
stroke:fix 300 mm
no. of strokes:20 - 70 Hub/min
distance between columns:3100 mm
side window:1400 mm
distance table/ram, max. stroke up, adjustment up:1000 mm
Table area:2800 x 1600 mm
ram surface:2800 x 1450 mm
ram adjustment:100 mm
power requirement:90,0 kW
weight:100,0 t
Dimensions (WxDxH):5,75 x 3,2 x 7,8 m
height above floor:6,4 m
height beneath floor:1,4 m
clutch:pneumatic; Ortlinghaus
ram adjustment:motoric
overload protection in ram:hydraulic
ram counterbalance:pneumatic
