trabajo con chapas de metal usadas para la venta (3,368)

Completo con torre de almacenamiento automático de láminas

3000 x 1500mm / 5000w / Siemens 840 - Tecnología de cabezal único

3000 x 1500mm Truflow 5000w Cambiador automático de boquillas Cambiador de palets automático

Cabezal de punzonado Servo Electric Gran formato 3000 x 1500mm Con carros Sheet Master & Duplex Año: 2015 ¡Menos de 19.000 horas! Con herramientas

BYSTRONIC PR 150 Ton x 4100mm Over Bed CNC Press Brake. Incluye control Cybelec DNC 1200 de 6 ejes. (Y1, Y2, X, Z1, Z2, R) Auto Crowing. Guardias láser. Abrazadera hidráulica de la herramienta superior. Cercas de seguridad laterales y traseras. Carousel de herramientas. S/No 04430044. Nuevo 2004.

Freno de prensa CNC de 250 toneladas x 5100 mm sobre la cama. Admitiendo 4500mm entre marcos laterales. Calibre de respaldo largo de 3000 mm. Incluye control Cybelec DNC 800 8 ejes. (Y1, Y2, X1, X2, Z1, Z2, R1, R2) Auto Crowing. Protectores de Operador Infra-Rojo. Abrazadera hidráulica de la herramienta superior. Cercas de seguridad laterales y traseras. Carousel de herramientas. S/No 97P288. Nuevo 1997

3000 x 1500mm 4400w BYVISION

3000 x 1500mm 6000w

3000 x 1500m 10 kW Máquina de corte láser de fibra

3000 x 1500mm Láser: 3300w

120 ton x 4100mm (3700mm entre bastidores) MODEVA 10 CNC Completo con STARMATIC ROBOT AUTOMATION PAQUETE DE HERRAMIENTAS PAQUETE SOFETWARE

Hidráulica de 3 rodillos con configuración planetaria doble pre-pinch. nuevo para completar, 45 días a partir del pedido. -Ancho de placa 3000 mm -Espesor de la placa de rodadura de la capacidad 50 mm -Espesor de la placa de pre-pellizco 40 mm Configuración de la máquina y accesorios instalados: -longitud útil de la superficie en los rollos 3100 mm -tamaño del rollo superior 480 mm -tamaño inferior de los rodillos 440 mm -Lecturas de posición digital. -Tratamiento de endurecimiento de los 3 rollos. -3 rollos accionados hidráulicos motorizados con caja de engranajes axial independiente en cada rollo. -Fijación de flexión de placa cónica con rollos inferiores inclinables hidráulicos. -Certificación de calidad CE, fabricación Made in Italy. -Manuales de servicio e instrucciones de funcionamiento. -Diagramas hidráulicos -Esquemas eléc ...

320 toneladas x 4100mm

Dobladora de placas Kramatorsk de 4 rodillos Resistencia máxima a la tracción del material: 500 MPa (50 kg/mm²) Límite elástico – flexión en frío: 250 MPa (25 kg/mm²) Límite elástico – flexión en caliente (primario): 100 MPa (10 kg/mm²) Límite elástico – conformado en caliente (calentamiento secundario): 45 MPa (4,5 kg/mm²) Elongación en frío: ±18% Ancho máximo de la hoja: 4000 mm Espesor máximo de la chapa, en frío, sin precurvado: 71 mm Espesor máximo de la chapa, en frío, con predoblado: 63 mm Espesor máximo de la chapa – conformado en caliente: 150 mm Radio de curvatura mínimo – frío: 560 mm Radio de curvatura mínimo – en caliente: 600 mm Radio máximo para plegado cerrado (borde rizado): 1000 mm Motor principal: 160 kW Peso: 730 toneladas

sheet width:400 mmplate length:500 mmplate thickness:4 mmtotal power requirement:0,5 kWPunching and Nibling machine with 6 x 3 mm nibling and 4 mm for cuting

material width:600 mmmaterial thickness: - 4,0 mmno. of straightening rolls:21 straightening roll diameter:30 mmmaterial cross-cut:1800 mm²speed:6 - 36 m/minPower capacity:4,5 kWWeight:2,0 tDimensions (WxDxH):1,5 x 2,0 x 1,9 m

material width:70 mmmaterial thickness:0 - 1,5 mmfeed length:100 mmmaterial cross-cut:60 mm²feeding force:400 Nclamping force of feeding pincer:1300 Nair pressure - required:3 - 6 barWeight:0,01 tDimensions (WxDxH):0,4 x 0,4 x 0,7 m

sheet width:2000 mmplate thickness:1.8 mmControls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mmRAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /minRAM (MECHAN. PRESS):. - ram adjustment:350 mmTOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mmDECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. di ...

band width:1050 mmplate thickness:8 mmnumber of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mmFEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mmLEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/minELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 HzTechnical description :Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of:- LAWECO COIL LO ...

Deburring and fine grinding machine for sheet metal / flat material, newThe compact machining centre for deburring, slag removal, rust removal, oxide layer removal, edge rounding, fine grinding through to polishing metal surfaces.Working height: variable from 0,5mm ? 150mm adjustableWorking width: 1150 mmMaximum part weight: 300 kgWide belts with abrasive belt unwinding: 2200 mmAs standard with vacuum hold system, optional with magnetic hold systemDue to the modular design of the machines, it is possible to offer the optimal configuration for the customer's machining task.The machine structure can accommodate up to 3 internal machining units and an additional external machining unit.Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

Deburring and fine grinding machine for sheet metal / flat material, newThe compact machining centre for deburring, slag removal, rust removal, oxide layer removal, edge rounding, fine grinding through to polishing metal surfaces.Due to the fixed working height, this machine can also be optimally integrated into a production line and is suitable for machining large parts.Working width: 1350 mmMaximum part weight: 400 kgWide belts with abrasive belt unwinding: 2620 mmAs standard with vacuum hold system, optional with magnetic hold systemBy using 2620 mm long abrasive belts, you get a uniformly smooth surface and reduce consumption costs, as these belts have a longer service life.Due to the modular design of the machines, it is possible to offer the optimal configuration for the customer's machining task.The machine structure can accommodate up to 3 internal machining units and an addition ...

Deburring and fine grinding machine for sheet metal / flat material, newThe compact machining centre for deburring, slag removal, rust removal, oxide layer removal, edge rounding, fine grinding through to polishing metal surfaces.Due to the fixed working height, this machine can also be optimally integrated into a production line and is suitable for machining large parts.Working width: 1150 - 1350 mmMaximum part weight: 500 kgWide belts with abrasive belt unwinding: 2620 mmAs standard with vacuum hold system, optional with magnetic hold systemBy using 2620 mm long abrasive belts, you get a uniformly smooth surface and reduce consumption costs, as these belts have a longer service life.Due to the modular design of the machines, it is possible to offer the optimal configuration for the customer's machining task.The machine structure can accommodate up to 5 internal machining units and 2 ad ...

Deburring and fine grinding machine for sheet metal / flat material, newThe compact machining centre for deburring, slag removal, rust removal, oxide layer removal, edge rounding, fine grinding through to polishing metal surfaces.Machine is suitable for heavy-duty use.Due to the fixed working height, this machine can also be optimally integrated into a production line and is suitable for machining large parts.Working width: 650 - 1650 mmMaximum part weight: 2000 kgWide belts with abrasive belt unwinding: 3250 mmAs standard with vacuum hold system, optional with magnetic hold systemBy using 3250 mm long abrasive belts, you get a uniformly smooth surface and reduce consumption costs, as these belts have a longer service life.Due to the modular design of the machines, it is possible to offer the optimal configuration for the customer's machining task.The machine structure can accommodate up ...

sheet width:5040 mmplate thickness:2 mmtotal power requirement:12 kWweight of the machine ca.:9,4 tdimensions of the machine ca.:6200× 1300 ×1900 mmworking width:5000 mmcontrol:Fasti Matik stroke of upper beam:500 mmadjustment of lower beam:u.Biegewange 80 mmcontrol cabinet:1000 x 850 x1450 mmDocuments:vorhanden

material width:180 mmcoil weight:0,75 tmaterial thickness:2,0 - 6,0 mmcoil external diameter:400 - 1250 mmno. of straightening rolls:5 number of draw-in rolls:2 band speed:20 m/minpower requirement:4,0 kWweight:2,8 tdimensions (WxDxH):1,4 x 2,45 x 1,85 msnubber roll:pneumatic

material width:150 mmmaterial thickness:1,5 mmpower requirement:3,0 kWno. of straightening rolls:7 straightening roll diameter:50 mmnumber of draw-in rolls:4 weight:0,67 tDimensions (WxDxH):1,3 x 1,1 x 1,6 m

material width:150 mmmaterial thickness:2,5 mmfeed length:100 mmcompressed air:6 barclamping force of fastening pincer:2000 Nclamping force of moving pincer:2000 Nfeeding force:1200 Nweight:0,1 tDimensions (WxDxH):0,35 x 0,85 x 0,5 m

material width:850 mmmaterial thickness:0,3 - 1,5 mmno. of straightening rolls:8 straightening roll diameter:40 mmnumber of draw-in rolls:2 diameter of draw-in rolls:160 mmmaterial thickness with 600 mm material width:1,9 mmmaterial thickness with 400 mm material width:2,3 mmspeed:5 - 25 m/minmin. material width:200 mmweight:2,8 tDimensions (WxDxH):1,6 x 2,2 x 2,3 m

material width:850 mmmaterial thickness:0,3 - 1,5 mmno. of straightening rolls:8 straightening roll diameter:40 mmnumber of draw-in rolls:2 diameter of draw-in rolls:160 mmmaterial thickness with 600 mm material width:1,9 mmmaterial thickness with 400 mm material width:2,3 mmspeed:5 - 25 m/minmin. material width:200 mmweight:3,1 tDimensions (WxDxH):2,2 x 1,5 x 2,8 m

material width:300 mmmaterial thickness:- 3,0 mmno. of straightening rolls:7 Stückstraightening roll diameter:60 mmweight:0,8 tDimensions (WxDxH):0,9 x 1,5 x 1,4 m
