STUDER S 33 Rectificadoras para cilindrado exterior

CONTROLS
  CNC controls FANUC 0I-TFP
WORKING RANGE CYLINDRICAL GRINDING
  swing diameter (max): 350 mm
  workpiece weight between centers (max): 80 kg
WORKING RANGE EXTERNAL GRINDING
  grinding diameter (max): 350 mm
  grinding length: 400 mm
WORKPIECE SPINDLESTOCK
  spindle revolutions (max): 1500 /min
  drive power: 3 kW
  spindle bore diameter: 30 mm
  tool fixture: MK 5
  c-axis: yes
  - positioning/indexing: 0.5 °
TAILSTOCK
  distance betw. centers (max): 400 mm
  sleeve stroke: 60 mm
  taper: MK 4
SPINDLESTOCK GRINDING SPINDLE
  X-axis travel: 370 mm
  Z-axis travel: 500 mm
  tilting range (B-direction) min: 60 °
  drive power: 9 kW
GRINDING TOOL
  diameter (max): 500 mm
  borehole: diameter: 203.2 mm
  width: 63 mm
ELECTRICAL SPECIFICATIONS
  mains voltage: 400 V
  mains frequency: 50 Hz
DIMENSIONS / WEIGHTS
  total weight approx.: 8500 kg
ONLY 1700 operating hours!
Travel X1: 370mm
Infeed X1: 0.001-15000m/min
Resolution X1: 0.00001mm
Travel Z1: 500 mm
Infeed X1: 0.001-20000m/min
Resolution X1: 0.00001mm
incl. measuring control
- Longitudinal position and circumferential position
