Petschauer ADM 800

Suitable specifically for turning out drillings on HM-equipped saw blades, CV saw blades and bases from a diameter of 80 to 800 mm Ø., Turning time with on and off clamping: 4 minutes , drive power: 2.2 kW with stepless speed regulation via frequency converter, Threading device: Equipped with a cross slide with adjustable dovetail guidance + locking levers, Travel stroke X-axis: about digital display max 200 mm, Y axis: about hand spindle 120 mm , Magnetic holding force: 10 kg/cm², magnet: Suitable specifically for turning out drillings on HM-equipped saw blades, CV saw blades and bases from a diameter of 80 to 800 mm Ø., Dimensions W x D x H =: 1700 x 900 x 1750 mm , mass: 650 kg
