GEA Nu-Con CV 375 C Instalaciones para el envasado

The GEA Nu-Con CV 375 C is a Convey Through Sanitary Rotary Valve (Airlock) for use in gravity or pneumatic conveying systems, handling food, dairy, pharmaceutical, nutritional products and other dry ingredients. Quick disassembly without tools allows for rotor removal and access to all product contact areas for inspection and cleaning. The rotary valve has 8 bladed cylindrical rotors and accurately gauged clearances are maintained between the rotor tips and ends within the valve bore. Blow through (CV) with product entering at the top and discharging horizontally at 90 ° to inlet via a pneumatic conveying line, either vacuum or pressure. Previously used for transporting of Casein in a dairy factory. Material: SS SS AR. Drawing No. A3-33456-01. Motor: 0,25 kW - 220-240 / 380-415 V @ 50 Hz or 240-266 / 415-460 V @ 60 Hz - 1.300/27 rpm or 1600/34 rpm - 1,27/0,73 Amp or 1,15/0,66 Amp - 3 Ph. SEW Eurodrive R47/A gearbox, 1.300/17 rpm - i 76,23, Ma max: 300 Nm., Type of Machine: Sanitary rotary valve, Stock Number: 1417, Swept Vol. (cu ft): 0,18, Swept Vol. (liter): 5,10, Current motor: 0,25 kW - 1.300/27 rpm or 1600/34 rpm, Shaft diameter: 1 3/16 (3 cm), Outside Diameter Flange: 13 1/2 (34 cm), Inside Diameter Flange: 8 (20,3 cm)
