otras máquinas para el procesado de madera usadas para la venta (1,280)

machine 1:Fixed side at the left, working width 220 mm to 2500 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 10 - 40 m/minChain infeed taking 1,62 m. panels in front of the dogsPanel alignment at the infeedMiddle supportNC 30 controllsEquipment left and right:1+1 Jump universal shaper 6 kW1+1 Twin hogging unit, motors 6,6 kW (2 motors)1+1 Universal shaper 6 kW1+1 Jump universal shaper 6 kWpanel turning device HOMAG TD 31/30/13Year 1989machine 2:Fixed side at the left, working width 220 mm to 3000 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 8 - 40 m/minChain infeed taking 1,62 m. panels in front of ...

Trituradora de tambor con empujador hidráulico Ancho del tambor de la navaja: 800 mm Boca 800 x 1200 mm Motor: 18,5 kW Diámetro de conexión de extracción 200 mm

Semiautomático

Ancho máximo de trabajo: 1300mmGrosor máximo de trabajo: 140mm. Ancho de mecanizado: 1300mmRodillos de alimentación motorizados2 unidades de cepillado

Workpiece thickness: 8 - 90 mm, electronically adjustableFeed rate: 18-32 m/min frequency controlledEdge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mmEquipment:Inlet guide automatically adjustable via the control, extension 500 mmJoint milling unit: 2 x 3.0 KWworkpiece preheatingGluing unit A34edging magazine for rollPressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the controlCutting unit WK14, straight, 2 motors 0.8 kWPre-milling unit: 2 x 1.5 KW, pneumatic adjustmentForm milling unit FF 12 automatic, 2 motors 0.4 kWradius/phase milling unit FF12 automatic 4 motors 0.4 KWuniversal milling aggregate controlled UF11, 4 kWProfile scrapers PN20Glue scrapersNozzles for detergent and anti-stickPolishing unitControl: Power Control PC22

Campo de trabajo: eje x: 3200 mm, eje y: 944 mm, eje z: 110 mmVelocidad máxima programable: eje x: 100 m/min, eje y: 75 m/min, eje z: 15 m/minPortaperforadores: diámetro 10 mmVelocidades del husillo: 4000 rpmSierra de ranura: diámetro 120 mmHuecos de taladro: 24 husillos horizontales en X, 10 husillos verticales en XPresión de trabajo presión de aire, presión de aire: 6 barPotencia instalada: máximo 25 kWC Eficiencia de las herramientas de vacío: 40 m?/hCNC: pantalla: monocromática 9? Unidad de disquete

Machining center in vertical designWorkpiece dimensions:Length 200 to 3050 mmWidth 70 to 850 mmThickness 12 to 60 mmMax workpiece weight 35 kg1 milling spindle 10 kW (HSK63)with tool changer with 4 positions13 independently callable vertical drilling spindles4 independent horizontal drilling spindles in X2 horizontal drilling spindles in Y1 grooving cutter in XWood WOP operating softwareWood WOP import basicDXF import basicOperating language: nl, de, enWoodwop 7 Office license included

Single sided postforming line, capable of doing L - and U profiles, with or without insert.Workpiece thickness: 16 to 60 mm.Min. workpiece width: 150 mm.Workpiece overhang: 70 mm.Max. laminate overhang: 105 mm.Feed speed 3 - 18 m/min.Fence side at the leftEquipment:Squaring and shaping part:1 x Postforming squaring unit, 2 motors each 1kW, 1st motor removing the laminate, 2nd motor trimming the overhaning laminate1 x scoring, motor 1 kW, top position1 x milling unit for the laminate when doing U profiles 1 x laminate support Postforming part1 x blow cleaning nozzle 6 x glue nozzle for the glue application 2 x glue roller9 x IR heating, each 2,2 kW2 x Hot air blower, each 10 kW1 x Basic postforming pressure zone for L-profiles, using rollers1 x Basic postforming pressure zone for U-profiles, using rollers1 x VF postforming pressure zone for special profiles, using pressure pathsFinishing  ...

Fixed side at the leftPanel thickness min/max: 16/45 mmMin. panel width: 150 mmLateral panel support for panel width up to 900 mmMin/max. panel length: 700 / 3100 mmMax. laminate overhang: 110 mmMax. laminate thickness: 0,8 mmRadius min/max: 6 / 22 mm (depends the laminate)Feedspeed max. 18 m/minTop pressure by beltEquipment:Infeed fence, adjustable, defines the panel overhang2 x trimming unit 0,4 kW, HSK 25 toolholder1 x PVAc glue application5 x glue nozzle, adjustable1 x hot air blower3 x IR heating on top (55 cm length), 3 x bottom (90 cm length)Postforming zone 1,8 m. lengthVarious pre-installed profiling sets 1 x top trimmer 0,4 kW

Grosor de la pieza: 8 - 50 mm Grosor de filo: bordes de la bobina 0,4 - 3 mm Velocidad de avance 10 m/min Equipamiento: ajuste manual de altura. Unidad de fresado de juntas, 2 motores Calentamiento de bordes del panel Área de pegado Zona de presión Rodillos accionados 1 y 2 no accionados ¿Acabados finales, 2 motores de 0,8 kW, recto y biselón 15? Corte superior e inferiorUnidad de raspado de perfil para bordes de PVCRaspadores de pegamento

Min./max. thickness edge banding on roll: 0,4 - 3mmMin./max. thickness edge banding in strips: 5 mmMin./max. panel thickness: 8 - 50mmMin. panel length/width: 190/110mmThroughput speed: 9m/minPre-milling unit: 2,2kW 7200 rpmSprayers release agentPanel heating device Automatic laoding for edgesGluing unit: 0,18kWEnd-cutting unit with radius: 0,19kWTrimming unit: 2x 0,35kW, 12000rpmRounding unit up to 3mm: 0,35kWEdge scraping unitSprayers cleaning agentGlue scraping unitBrushing unit

Ajuste motorizado de alturaCaja acústica sobre todos los motores de recorteEquipo: Cargador de bobinas y tirasUnidad de fusión caliente Zona de presión Trimes finales, bisellín y recto, ajuste automático Corte rugoso arriba/abajo Recorte fino arriba/abajo, inclinación, unidad de recorte de contorno Unidad de raspado Unidad de pulido transportador de retorno Ligmatech ZHR 05

4-side squaring and edge banding lineMachine 1:Fixed side right, moving side leftRolling chain, feed 10 - 40 m/minControlls NC 21Panel thickness 8 - 60 mmMax. panel width 1500 mmEdges: coil 0,3 - 3 mm, strips 0,4 - 20 mmEntry fence for veneered panelsEquipment:1+1 Compact-twin hogger, 2 motors 6,6 kW1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application1+1 Free space for solid wood edges up to 2,54 m length1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm)1+1 Universal shaper 8,1 kW1+1 Universal shaper 8,1 kW1+1 Edge sander KS 101+1 Disc sander DS 401+1 Disc sander DS 40Angular transfer to the right, TWR 24/30/12/SPanel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mmMachine 2Machine II + infeed magazine TW 24Fixed side right, m ...

Panel thickness: 8 - 50 mmThickness of the edges: 0,4- 3 mmFeed speed 8 - 11 m / minPU pressure rollersEquipment:Squaring unit, 2 motors 2,2 kWPanel edge heatingEdge magazine for coil and stripsHot melt application with rollerAirtec AT4510 unitThe Airtec aggregate is positioned so you can use Airtec or the standard glue potMotorized side pressure unitEnd trims, 2 motors, pneumatic positioning straight and with chamfertrimming unit above / belowContour trimming unitProfile scraping unitGlue scraping unitPolishing unitDetergent spray systemcentral lubrication

Single sided edge bander with hot melt, fixed side at the right, pre-milling unitEdge thickness: 0,4 to 12 mmWorkpiece thickness: 8 - 60 mmFeedspeed 8-20 m/min (limited to 10 m/min using the contour trimming)Workpiece transport by chain, top pressures with rubber rollersSound enclosure over all trimming motorsEquipment:Adjustable fencePre-milling with 2 shapers, each 2,2 kWCoil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollersEnd trims, 2 x 0,35 kW motors, straight and chamfer 15?Top/bottom trimming, motors 2 x 0,35 kWRadius trimmmingContour trimming unit, leading and following edge, 2 x 0,35 kWRadius scraping unitGlue scrapersBuffing unitControlls PC 20+

Área de trabajo: X 5200 x Y 1260 mmCabezazo del husillo principal: X 5709 mm, Y 1650 mm8 Consolas de pieza de trabajoEquipamiento: Unidad de perforación con 18 husillos, 12 pinchas verticales, 6 husillos horizontales (4 en dirección X, 2 en dirección Y) Sierra de surcoMotor de fresado 11 kW, máximo 20000 rpm, HSK-F 63 de recogida, refrigerado por líquido, controlado por 5 ejesCambiador de herramientas con 16 posicionesCambiador posicionado lateralmente con 8 posicionesControl por PC. Control por PC

Working field: axis x: 2310 mm, axis y: 628 mm, axis z: 90mmMax programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/minDrill chuck: diameter 10 mmSpindle speeds: 4000 rpmGrooving saw: diameter 120 mmDrill spindles: 4 horizontal spindles in X,12vertical spindles in X lineWorking air pressure: 6 barMax consumption of compressed air: 0,75 NL/cycleInstalled power: max 7.5 kWCapacity of vacuum tools: 40 m?/hCNC:screen: monochromatic 9?Floppy disk unitPLC for control of the machine cycle

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Workpiece sizes: Length 180 - 2500 mm, width 150 - 800 mm, thickness 12 - 40 mmFixed side at the left, motorised width adjustment of the right side Working height/ transport height: 920 mmWorkpiecetransport with belts, infeed belts can lift upVariable feed speedEach side has got 5 glue injectors and 8 dowel inserters (Type 34)Doweldiameter: 8 mm, dowellength 30 mm, dowelprojection 7-14 mm, dowelcenters min. 32 mm, max. 736 mmEach side with dowel hopper feed with shaker and separatorsControll mirrorGlue pump 1:1 Glue injection controlls type ELC

X=3700mm Y=1440mm, Z=150mmMoving speed: X: 80 m/min, Y: 80 m/min, Z: 20 m/min8 supports with vacuum cups, pneumatic clamping8 fences at the rear8 fences in front2 left fences and 2 right fences6 rails for panel loading with pneumatic liftingPositioning the vacuum cups using a laser1 connection for templatesVacuum pump with flow rate 100 m3/hConfiguration V25,H8X/6Y, N1 X-Y 90?, F1-HSK63-15KW,F1-HSK63-9KW, C axis, W14 rearMain motor 15 kW, 1250-24000 rpm, air-cooled, 360? C-axis, C-axis interpolation axis, HSK 63 mountingC axis extension for flex-5 aggregateMain motor 9 kW, 1250-24000 rpm, air cooled, HSK 63 mountingTool changer operating in X direction with 14 positions, rear mounted2 x 4 vertical X drilling pins, 2 x 3 vertical Y drilling pins14 horizontal drilling spindles90? groove saw X-Y directionPC 85 power control software with:Woodwop: workshop-oriented programming systemImport 2 ...

Machine designed for machining solid wood doors with frame and raised panelsWorkpiece dimensions Length 150 - 3000 mm Width 40 - 300 mm Thickness 20 - 60 mm Material: hard woods/soft woods Machine equiped with 2 working areas, including - 3 NC-axes X, Y, Z- telephone modem- 1 sawing unit- 1 horizontal boring unit- distance horizontal drill above table (Z):max. 40 mm- fixed workpiece table- central lubrication- CE package- max. workpiece length 2.400 mm KOCH Numeric with 3 NC-axes Positioning control with PC Pentium CPU Operating system Windows XP Professional: english 15? Touchpanel VGA + Touchscreen by means of LVDS connection USB-connection on PC and on Touchpanel Seriel and parallel interface on the PC Hard disk 2,5? Input of machine commands and motor control through the Touchpanel PS2 connection for external keyboard Office PC software Stretched machine bas for max. workpiece width ...

Working width 180 - 3200 mm, electronic setting Sieb & MeyerFixed side at the leftChain transport, 80 mm wideInfeed for panels of about 1 m.Top pressure by driven beltsMax. workpiece thickness: 80 mmFeedspeed 7 - 35 m/min, motor 2,2 kWPop-up dogs every 1m10Equipment left / right:1 st postFront: 1+1 Jump scorer, motor 1,5 kW, 100 Hz, joined to 1+1 Hogger, motor 3 / 4,4 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 Hz2nd postFront: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzRear: 1+1 Fixed milling, tilting, motor 2,2/3,3 kW, 50/100 Hz3th postFront: 1+0 Jump milling, tilting, motor 2,2/3,3 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzAll units with horizontal/vertical adjustment and Siko read-outOutfeed chain approx. 80 cm lengthSound and safety enclosures

Versión derecha Sierra de corte: 1,5 kW2 x eje horizontal: 2 x 1,5 kW1 x eje vertical, diámetro 50 mm, longitud 160 mm, 2,2 kW

Versión derecha Dimensiones de la pieza: longitud máxima 3000 mm, mínimo 250 mm, grosor máximo 100 mm, mínimo 30 mm, ancho 200 mm Sierra de corte aérea, 3 kW, 3000 rpm, movimiento horizontal manual sobre 120 mm, hoja de 400 mm, altura de corte 100 mm1 Eje vertical, 340 mm de longitud, 40 mm de diámetro, 7,5 kW, 3100 rpm, orificio de succión con 150 mm de diámetro (x2), Diámetro máximo de la herramienta: 320 mm. Carro con sujeción neumática: 1100 x 500 mm. Tope, posicionamiento desde -45? ¿A 45? Carruaje motorizado con control electrónico 2-32 m/min

Escáner de calidad fabricado en 2014. Este MICROTEC GOLDENEYE GLD 600 DSC está diseñado para la inspección de grandes placas y paneles de hasta 1,8 metros de ancho. Integra cámaras geométricas, visuales y de rayos X multisensor para evaluar tanto las propiedades externas como internas de la madera, proporcionando una evaluación exhaustiva de la calidad del material. Si buscas obtener capacidades de inspección de alta calidad, considera la máquina MICROTEC GOLDENEYE GLD 600 DSC que tenemos a la venta. Contáctanos para más detalles.

Este FORMAT4 TEMPORA 60.06 TEMPORA 60.06 ILLA x-motion edgebander fue fabricado en 2024. Cuenta con un cargador de plato giratorio con un diámetro de 750 mm para material de borde que va de 0,4 a 3 mm, una unidad de aplicación GlueBox y unidades de pulido superior e inferior. La máquina incluye un avanzado control x-motion Plus con una pantalla SmartTouch de 15 y una unidad multifuncional de fresado para mecanizado preciso de bordes plásticos. Contacta con nosotros para más información sobre esta máquina.

Inv. Num. : 8894 Tipo: B24-TH300 DX/DW PU Productor: H&H Maschinenbau Creado: 2020 Parámetros: Peso: 498 kg Equipamiento: Máquina de fusión PUVS 280 P para tambores de 20 kg de adhesivo PUR

Inv. Num. : 8874 Tipo: TRIATLÓN 1487 V Productor: HOLZHER Creado: 2003 Parámetros: Altura de la fijación: 55 mm Dimensiones de la máquina: 7500 x 1300 x 1800 mm

Núm. Inv. : 8663 Tipo: Opticontrol Productor: Weinig Generado: Parámetros: Diámetro máximo de la herramienta: 300 mm Longitud máxima de la herramienta: 330 mm
